Tipe Mesin |
4-Stroke DOHC 4-valve Single Cylinder |
Tipe Transmisi |
6-speed Manual |
Tipe Kopling |
Multiple Wet Clutch with Coil Spring |
Tipe Starter |
Electric |
Diameter x Langkah |
76 x 55 mm |
Volume Langkah |
249,67cc |
Daya Maksimum |
18,9 kW / 8.500 rpm |
Torsi Maksimum |
23,1 Nm / 6.500 rpm |
Busi |
- |
Sistem Bahan Bakar |
PGM-FI |
Pengapian |
- |
Tipe Pendingin |
Liquid-cooled |
Perbandingan Kompresi |
10,7 : 1 |
Pola Perpindahan Gigi |
1 - N - 2 - 3 - 4 - 5 - 6 |
Jenis Pelumas |
Wet |
Tipe Rangka |
Semi-Double Cradle, Steel |
Tipe Suspensi Depan |
Showa, 43mm Inverted Telescopic |
Tipe Suspensi Belakang |
Alumunium Swing Arm, Showa 260 Axle Travel with Pro-Link |
Ukuran Ban Depan |
80/100 - 21M/C 51P |
Ukuran Ban Belakang |
120/80 - 18M/C 62P |
Tipe Rem depan |
256mm Wavy Disc Brake, Dual Piston Calipers |
Tipe Rem Belakang |
220mm Wavy Disc Brake, Single Piston Calipers |
Sistem Pengereman |
- |
Panjang x Lebar x Tinggi |
2.229 x 903 x 1.203 mm |
Jarak Sumbu Roda |
1.453 mm |
Jarak Terendah Ke Tanah |
277 mm |
Ketinggian Tempat Duduk |
893 mm |
Berat Kosong |
140 kg |
Kapasitas Tangki Bahan Bakar |
7,8 liter |
Kapasitas Minyak Pelumas |
1,35L |
Tipe Baterai Atau Aki |
MF-Wet 12V-7Ah (10h) |
Sistem Pengapian |
Full Transisterized |
Tipe Busi |
NGKSIMR8A9 |
Power Charger |
- |
