Tipe Mesin |
Air-Cooled, 4-Stroke, SOHC Single Cylinder |
Tipe Transmisi |
Manual, 4-speed |
Tipe Kopling |
Wet, Multi-plate Coil Spring |
Tipe Starter |
Electric & Kick |
Diameter x Langkah |
50 x 63,1 mm |
Volume Langkah |
124 cc |
Daya Maksimum |
6,76 kW / 6250 rpm |
Torsi Maksimum |
10,8 Nm/4.750 rpm |
Busi |
- |
Sistem Bahan Bakar |
PGM-FI (Programmed Fuel Injection System) |
Pengapian |
- |
Tipe Pendingin |
- |
Perbandingan Kompresi |
10 : 1 |
Pola Perpindahan Gigi |
- |
Jenis Pelumas |
- |
Tipe Rangka |
Backbone, Steel |
Tipe Suspensi Depan |
Telescopic Suspension |
Tipe Suspensi Belakang |
Twin Rear Suspension |
Ukuran Ban Depan |
80/90-17M/C 44P |
Ukuran Ban Belakang |
80/90-17 M/C 50P |
Tipe Rem depan |
220mm Hydraulic Disc |
Tipe Rem Belakang |
190mm Hydraulic Disc |
Sistem Pengereman |
ABS 1 Channel |
Panjang x Lebar x Tinggi |
1961 x 805 x 1.085 mm |
Jarak Sumbu Roda |
1.258mm |
Jarak Terendah Ke Tanah |
165 mm |
Ketinggian Tempat Duduk |
800 mm |
Berat Kosong |
116 kg |
Kapasitas Tangki Bahan Bakar |
5,3 L |
Kapasitas Minyak Pelumas |
0,8 L |
Tipe Baterai Atau Aki |
- |
Sistem Pengapian |
Full Transisterized |
Tipe Busi |
NGK CPR7EA-9S |
Power Charger |
- |
