Tipe Mesin |
4-stroke SOHC 2-Valve |
Tipe Transmisi |
Manual, 5-Speed |
Tipe Kopling |
Wet, Multiple Clutch |
Tipe Starter |
Electric |
Diameter x Langkah |
50 x 63,1 mm |
Volume Langkah |
124 cc |
Daya Maksimum |
6,9 kW / 6.750 rpm |
Torsi Maksimum |
11 nM / 5.500 rpm |
Busi |
- |
Sistem Bahan Bakar |
PGM-FI |
Pengapian |
- |
Tipe Pendingin |
Air-cooled |
Perbandingan Kompresi |
10 : 1 |
Pola Perpindahan Gigi |
- |
Jenis Pelumas |
- |
Tipe Rangka |
Back Bone Steel |
Tipe Suspensi Depan |
Showa, 31 mm Inverted Telescopic Fork |
Tipe Suspensi Belakang |
Showa, Twin Shock |
Ukuran Ban Depan |
120/80-12 65J |
Ukuran Ban Belakang |
130/80-12 69J |
Tipe Rem depan |
Hydraulic, Single 220 mm disc with ABS |
Tipe Rem Belakang |
Hydraulic, Single 190mm disc |
Sistem Pengereman |
ABS Single Channel |
Panjang x Lebar x Tinggi |
1.710 x 755 x 1.030 mm |
Jarak Sumbu Roda |
1.145 mm |
Jarak Terendah Ke Tanah |
175 mm |
Ketinggian Tempat Duduk |
775 mm |
Berat Kosong |
104 kg |
Kapasitas Tangki Bahan Bakar |
5,6 L |
Kapasitas Minyak Pelumas |
0,9 L (Periodic Exchange) |
Tipe Baterai Atau Aki |
12V-3Ah |
Sistem Pengapian |
Full Transisterized |
Tipe Busi |
NGK CPR7EA-9S |
Power Charger |
- |
